The Schneider Electric MTN6725‑0004 (REG‑K/2/16/64) is a KNX‑to‑DALI gateway that enables seamless integration of lighting control via two independent DALI channels. Each channel supports up to 64 DALI ballasts, organized in up to 16 groups and 16 scenes. It includes an integrated DALI power supply (Category I, DALI‑2 certified) and supports advanced DT‑8 color-temperature control—ideal for modern smart buildings and lighting automation.

Key Features:

• Part Number: MTN6725‑0004 (REG‑K/2/16/64), 2-channel version ()

• Bus & Power: KNX‑powered, 100–240 V AC supply, integrates two DALI power supplies, no external supply required

• DALI Capacity: Up to 64 ballasts per channel (128 total), 16 groups and 16 scenes per channel

• Color Support: DT‑8 (Tun‑White, RGB, XY, HSV, RGBW) with scene/timer management via ETS5 Device Control App

• Commissioning: Manual front buttons & LEDs, ETS5 DCA for addressing, fault detection, emergency/panic modes

• Dimensions: 4-module DIN‑rail housing (72×90×65 mm), IP20, local LED indicators

• Compliance: DALI‑2 certified, EN 62386‑103 Cat I, KNX, REACH/RoHS

• Firmware: Updateable via KNX, hardware version 0B, firmware ~v0.2.6
