Siemens - 6SE9213-6CA40 - MICROMASTER MM75/2 Frequency Inverter, 0.75 kW

The Siemens 6SE9213-6CA40 is a MICROMASTER MM75/2 frequency inverter designed for precise control of AC motors in industrial applications. With a power rating of 0.75 kW, this unfiltered inverter operates within an input voltage range of 208 to 240 V AC and is suitable for both single-phase and three-phase power supplies. It offers reliable motor control with a constant torque output and an overload capacity of 150% for 60 seconds.

Key Features:

• Power Rating: 0.75 kW (1 HP)

• Input Voltage: 1-phase or 3-phase, 208-240 V AC ±10%, 50/60 Hz

• Output Current: Rated at 3.9 A

• Control Method: Provides constant torque with an overload capacity of 150% for 60 seconds

• Dimensions: 175 mm (H) x 73 mm (W) x 141 mm (D)

• Protection Class: IP20

• Ambient Temperature Range: 0°C to +50°C

Applications:

• Conveyor systems

• Pump and fan control

• Material handling equipment

• General industrial machinery requiring variable speed motor control

Technical Specifications:

• Input Voltage: 1-phase or 3-phase, 208-240 V AC ±10%

• Input Frequency: 50/60 Hz

• Rated Output Current: 3.9 A

• Overload Capacity: 150% of rated output current for 60 seconds

• Dimensions: 175 mm (H) x 73 mm (W) x 141 mm (D)

• Weight: Approximately 0.75 kg
