Schneider Electric - LMC078CECS20T - Motion Controller
The Schneider Electric LMC078CECS20T is a motion controller from the Modicon LMC078 range, designed for coordinated, synchronized, and interpolated motion control in industrial automation applications. This compact controller offers 20 discrete I/Os and integrates seamlessly into various automation systems. It features a 24V DC power supply and includes a 3V lithium battery for memory backup. The controller supports SERCOS communication and is equipped with Ethernet and CANopen interfaces, facilitating efficient connectivity with other devices and networks. Please note that this product was discontinued by the manufacturer on January 23, 2021, and has been replaced by the Modicon M262 series.
Key Features:
• Coordinated Motion Control: Enables synchronized and interpolated motion for complex automation tasks.
• Discrete I/Os: Provides 20 discrete inputs/outputs for versatile control options.
• Multiple Communication Interfaces: Supports SERCOS, Ethernet, and CANopen protocols for flexible connectivity.
• Compact Design: Optimized for space-saving installations in control cabinets.
• Memory Backup: Includes a 3V lithium battery to maintain data integrity during power interruptions.
Technical Specifications:
• Model Number: LMC078CECS20T
• Power Supply: 24V DC
• Discrete Inputs: 24 total (12 regular, 8 fast, 4 capture)
• Discrete Outputs: 8 total
• Memory: 128MB NVRAM, 512MB RAM, 512MB SD card
• Communication Ports: SERCOS, Ethernet, CANopen
• Dimensions (W x D x H): 45mm x 220mm x 230mm
• Weight: Approximately 2.2kg
• Certifications: CE, CSA, UL
• Protection Rating: IP20
Applications:
• Industrial Automation: Ideal for controlling complex machinery requiring precise motion coordination.
• Robotics: Supports synchronized movements in robotic applications.
• Packaging Machines: Ensures accurate and efficient motion control in packaging processes.
• Material Handling: Manages coordinated movements in conveyor systems and automated storage solutions.
