Danfoss - 131B9057 - VLT® AutomationDrive FC 302, 0.75 kW, 3-Phase 380-500V AC,

The Danfoss VLT® AutomationDrive FC 302 (MPN: 131B9057) is a high-performance frequency converter designed for variable speed control of AC motors in industrial applications. Key features include:

• Power Rating: 0.75 kW (1.0 HP), suitable for small motor applications.

• Input Voltage: Three-phase 380-500V AC ±10%, 47-63 Hz, accommodating standard industrial power supplies.

• Output Voltage: 0 to input voltage, providing full control over motor speed.

• Output Current: 2.4 A, ensuring adequate power delivery to the motor.

• Overload Capacity: 160% of rated current for 1 minute, allowing for short-term load increases.

• Control Method: Advanced vector control and V/f (voltage/frequency) control, suitable for various applications requiring precise speed and torque control.

• Enclosure Rating: IP20 (Chassis), suitable for installation in controlled environments.

• Integrated Features:

• RFI Filter Class A1/B (C1) for electromagnetic compatibility.

• Graphical Local Control Panel (LCP) for intuitive operation and parameter setting.

• Standard cable entries for ease of installation.

• Dimensions (H x W x D): 268 mm x 90 mm x 205 mm, compact design for easy installation.

• Weight: Net weight of 5.59 kg, facilitating straightforward handling and mounting.

• Applications: Ideal for a variety of variable-speed drive applications, including pumps, fans, conveyors, and mixers, offering high performance and energy efficiency.
